AXIOME integrates the blade cutting process into cells with one or more polyarticulated robots, with simple or ultrasonic blades. These single or multi robot machines (from Stäubli, ABB...) follow the desired production pace and can be combined with robots also equipped with milling. The design of the machines, with automatic tool change, gives great flexibility of use and allows high speed use. As an indication, the average cutting speed is between 50 and 250 mm/sec.
The robotic blade cutting technology is perfectly adapted to flexible materials:
- Plastic films
- 3D foam
AXIOME has developed blade tools of the "knife" type with compliance. In the case where an "ultrasonic blade" head is used, the blade vibrates at high frequency to facilitate cutting. AXIOME has developed automatic blade change systems, which allows the cell to work independently: the robot can detect broken blades. The integration of ultrasonic blades on robots makes it possible to cut many materials, such as "dry" composites (carbon fibre fabrics for example) or pre-preg composites.
Blade cutting applications
Cutting of flexible materials
AXIOME technologies make it possible to cut flexible coatings such as decorative film, skin... for automotive parts. It is possible to integrate these features on one or two robots, or in addition to another cutting process such as milling, depending on the desired result.
Cutting of composite materials
AXIOME applications meet the needs of cutting composite materials such as dry fibre or prepreg.
Robotic skills and expertise
BENEFITS OF BLADE
- High cutting quality
- Low operating costs
- Control of the cutting depth
- Few consumable parts
- Reduced cutting force
- Cleanliness: no chips, no dust
- Operates autonomously
- Possibility of installation on a milling machine
TOOLS OF BLADE CUTTING
